A Professional Company Specializing In High-Precision Integrated Bearings

Founded in 2005, BOM has become a leader in the bearing industry by adhering to our core philosophy of "Unity and Effort." We specialize in providing integrated bearing solutions to high-end users, and as we have grown, we've expanded our focus to include three main business areas: bearings, guide rails, and motion units.

Home / Customization

Integrated Bearing Development Process

When developing an integrated bearing, we recommend providing specific details during the consultation phase. Sharing the following parameters and conditions can help ensure a precise and efficient development process:

Parameter 1:

Dimensions and Material

Outer Diameter: Specify the outer diameter of both the bearing and the bushing.
Material: Indicate the preferred material for the bearing and bushing, such as bearing steel or low carbon steel.

Parameter 2:

Bearing Bore Diameter and Bushing Length

Bore Diameter: Provide the diameter of the bearing bore.
Bushing Length: Specify the length of the bushing.

Parameter 3:

Performance Specifications

Maximum Torque and Static Torque: State the maximum torque and static torque requirements.
Noise Requirements: Indicate the acceptable noise levels during operation.
Maximum Speed: Provide the highest operational speed.
Eccentricity: Specify any allowable eccentricity.

Parameter 4:

Heat Treatment and Installation Dimensions

Heat Treatment: Choose between overall quenching, carburizing quenching, or high-frequency quenching.
Installation Dimensions: Provide the dimensions for the inner and outer rings.

Our Development Process

By following this structured process, we ensure that each integrated bearing we develop meets the highest standards of quality, performance, and reliability. Contact us today to discuss your specific requirements and start the development of your custom integrated bearing solution.

01

Consultation and Initial Design

During the initial consultation, our team will gather all the necessary parameters and requirements. This ensures that the design phase is tailored to meet your specific needs.

02

Material Selection

Based on the provided material specifications, we select the most suitable materials that offer optimal performance and longevity for the bearings.

03

Prototype Development

Using the specified dimensions and performance criteria, we develop prototypes to test and validate the design. This stage involves rigorous testing to ensure that the bearings meet the required torque, speed, noise, and eccentricity specifications.

04

Heat Treatment

The selected heat treatment process, whether overall quenching, carburizing quenching, or high-frequency quenching, is applied to enhance the bearing's durability and performance.

05

Precision Manufacturing

With the final design validated, we proceed to the precision manufacturing phase. Our advanced manufacturing techniques ensure that the bearings are produced to the highest standards of quality and accuracy.

06

Quality Control

Each bearing undergoes stringent quality control checks to ensure it meets all specified criteria. This includes checking for correct dimensions, material properties, and performance characteristics.

07

Delivery and Support

Upon completion of the manufacturing and quality control processes, the bearings are delivered to the client. Our support team remains available to assist with any installation or operational queries.
